U.L. 508A COMMERCIAL METER PEDESTALS
SPECIFICATIONS
Copyright © 2011 Pacific Electric, Inc. All Rights Reserved.
C-SERIES PEDESTALS
(C-SP224T-2-2)
STANDARD PEDESTAL
(SP222T)
12G. GALVANNEAL COATED STEEL CONSTRUCTION WITH 14G. DOORS & LID.

U.L. LISTED AS ENCLOSED INDUSTRIAL CONTROL PANEL.

RAINPROOF TYPE 3R CONSTRUCTION.

POLYESTER POWDER COATED FINISHES:
  ASA. #61 LIGHT GRAY
  RAL 6019 PASTEL GREEN
  RAL 6028 PINE GREEN

UNDERGROUND PULL SECTION IN BACK.

MEETS LOCAL UTILITY REQUIREMENTS.

SUITABLE ONLY FOR USE AS SERVICE EQUIPMENT.

PLUG-IN STYLE LOADCENTERS AND BOLT-ON PANELBOARDS AVAILABLE.


DUAL SOURCE MECHANICALLY INTERLOCKED
(SPDS222-QJ2H-MI)

SP221T
SP221-5T
SP221BR-LC10
SP221BRH-LC10
SP221BRHH-LC10
SP241-5T (SCE)
SP241T
SP341-5T
SP421T
SP441T
SP221T-LC10
100
100
100
100
100
100
100
100
100
100
100
120/240
120/240
120/240
120/240
120/240
277/480
240/480
480
120/208
277/480
120/240
CL. T F.P.O.
CL. T F.P.O.
BR
BRH
BRHH
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
4
5
4
4
4
5
4
5
7
7
4
42,000
42,000
10,000
22,000
42,000
30,000
10,000
30,000
42,000
30,000
42,000
-
-
10
10
10
-
-
-
-
-
10
CATALOGUE
NUMBER
AMPS
VOLTAGE
PHASE
MAIN
1PH. 3W.
1PH. 3W.
1PH. 3W.
1PH. 3W.
1PH. 3W.
1PH. 3W.
1PH. 3W.
3PH. 3W.
3PH. 4W.
3PH. 4W.
1PH. 3W.
STANDARD PEDESTAL
SP222T
SP222-5T
SP222T-1-1
SP242-5T (SCE)
SP242-5T-1-1 (SCE)
SP322-5T
SP422T
SP422T-DELTA
SP442FD
SP442T
SP442T-1-1
SP222T-LC10
200
200
200
200
200
200
200
200
200
200
200
200
120/240
120/240
120/240
277/480
277/480
240
120/208
120/240
120/208
120/208
120/208
120/240
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
FD6
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
4
5
4
5
5
5
7
7
7
7
7
4
42,000
42,000
42,000
42,000
42,000
42,000
42,000
42,000
42,000
42,000
42,000
42,000
-
-
-
-
-
-
-
-
-
-
-
10
1PH. 3W.
1PH. 3W.
1PH. 3W.
1PH. 3W.
1PH. 3W.
3PH. 3W.
3PH. 4W.
3PH. 4W.
3PH. 4W.
3PH. 4W.
3PH. 4W.
1PH. 3W.
SPDS222-QJ2H-MI
SPDS422-5QJ2H-MI
200
200
120/240
120/208
QJ2H
QJ2H
4
5
42,000
42,000
-
-
1PH. 3W.
3PH. 4W.
DUAL SOURCE MECHANICALLY INTERLOCKED
SPDS224-QJ2H-MI-2-2
400
120/240
QJ2H
4
42,000
-
1PH. 3W.
C-SP222T-1-1
C-SP242-5T-1-1
C-SP442T-1-1
200
200
200
120/240
277/480
120/208
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
4
5
7
42,000
30,000
42,000
-
-
-
1PH. 3W.
1PH. 3W.
3PH. 4W.
C-SERIES (COMPARTMENTIZED DISCONNECTS)
C-SP224-5T-2-2
C-SP224QJ2H-2-1
C-SP224QJ2H-2-2
C-SP224T-2-2
C-SP244-5T-2-2 (SCE)
C-SP324-5T-2-2
C-SP424T-2-2
400
400
400
400
400
400
400
120/208
120/208
120/208
120/208
277/480
240
120/208
CL. T F.P.O.
QJ2H
QJ2H
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
CL. T F.P.O.
5
5
5
5
5
5
7
42,000
42,000
42,000
42,000
30,000
42,000
42,000
-
-
-
-
-
-
-
1PH. 3W.
1PH. 3W.
1PH. 3W.
1PH. 3W.
1PH. 3W.
3PH. 3W.
3PH. 4W.
PADLOCKABLE COMPARTMENT
GENERATOR ACCESS DOOR
CLIP
AIC
CIRCUIT
